PVDF, 0.2µm, ø13mm, (Jar/150)
PSDSC-PV13-020-0150
PVDF, 0.2µm, ø13mm, (Jar/150)
| Product number |
PSDSC-PV13-020-0150 |
| Material |
PVDF |
| Pore size (µm) |
0.2µm |
| Diameter |
13 |
| Technical Parameters of Hydrophilic PVDF Filter |
| Diameter |
13mm |
25mm |
33mm |
| Housing Material |
Polypropylene |
| Filtration Area |
0,8 cm2 |
3,9 cm2 |
4,6 cm2 |
| Maximum Operating Pressure |
150 psi |
90 psi |
90 psi |
| Hold up volume, after air purge |
≤ 15µL |
≤ 30µL |
≤ 55µL |
| Pore Size |
0.1µm / 0.2µm / 0.45µm / 5µm |
| Inlet Connection |
Female luer lock |
| Outlet Connection |
Male Slip luer |
| Packing |
Non Sterile & Sterile |
